Pulsonic SonoPlus 3000DS ECG Recording Stethoscope
Manufacturer: BV Medical
Model Number: 3000-DS
Our Price: $1,195.00
Free Shipping

More Information

Pulsonic SonoPlus 3000-DS ECG Electrocardiogram Recording Cardioscope Stethoscope. The Pulsonic Company is based in Schlieren/Zurich, Switzerland. PULSONIC is a leading developer with pioneering experience, a manufacturer of high performance ECG and stethoscope instruments for heart rhythm monitoring solutions in human and veterinary medicine. Pulsonic's mission is to provide leading edge technology medical instruments and systems for physiological data acquisition and processing. Pulsonic's new generation of PC-based ECG recording cardioscopes for heart rhythm monitoring incorporate a number of technological innovations. If you have any questions regarding this item please give us a call (800)355-2956.



FEATURES:
- ECG and stethoscope in one unit
- ECG unit detachable from stethoscope tubing
- Pocket size and proven professional design
- Computer based ECG recording technology
- Special comb shaped gold-plated electrodes
- High-resolution display of the ECG and heart rate data
- Leads I - II -III
- Automatic pacemaker detection
- Auto scaling of ECG amplitudes
- Sampling frequency: 256 Hz
- Frequency response: 0.05/0.5 - 40 Hz (-3dB)
- Recording speed of 12.5, 25 or 50 mm/s
- Data storage (in-unit) up to 16 minutes and 99 patients records
- RS-232/USB PC-Interface
- Pulsonic software for data transfer to PC (PC-cable included)
- Battery duration: Approx. 120 hours
- Standard stethoscope plus "Anti-Interference-Technology", provides clear acoustics
- Tubing length: 68 cm (27") standard 60 cm
- Weight: Approx. 195 g



SPECIFICATIONS:
- ECG-recording: Via integrated three-point electrodes or with 3-lead patient cable
- Heart frequency indication: Rhythm; symbol on LCD-Display Numerical 30-240 bpm (±1%)
- Automatic turn-off: After 1 minute of no input
- Automatic ECG: Voltage amplification
- Myogram filter: ON/OFF through SONOPLUS Software on PC
- ECG-amplifier: Sampling frequency: 256 Hz
- Dynamic range: ± 5 mV
- Frequency response: 0.05/0.5 Hz– 40 Hz (-3 dB) manually selected
- Digital resolution: 12 bit
- Common mode rejection: > 80 dB
- Input Impedance: > 100 MOhms
- Output: via RS 232/USB interface
- Memory (in-unit): Storage capacity of 16 minutes and 99 patient records
- Battery duration: Approx. 120 hours
- Batteries: 2 pieces, 1.5 V, Type AAAA
- Environmental: 0 °C to 40 °C during operation (32 °F to 104 °F) -10 °C to 50 °C during storage (14 °F to 122 °F)



ADVANTAGES:
- Exceptional portability permitting omnipresence
- Compact electrocardiogram-stethoscope combination product designed to be carried around as easily as a standard mechanical stethoscope.
- Weight comparison: SONOPLUS 3000-DS about 200 g (7.1 oz); Standard mechanical stethoscope about 150 g (5.3 oz).
- Detachability of the SONOPLUS head (comprising electrocardiogram and stethoscope) from stethoscope tubing.
- Broad range of applications
- ECG recording capabilities, either through: Direct positioning of the SONOPLUS onto the patient’s left hemithorax
- Ideally suited for highly time-effective assessment of cardiac rhythm, conduction times and presence/absence of ischemia
- Allows recording of multiple “local” leads (“SONOPLUS leads”); Use of adhesive electrodes and 3-lead ECG cable
- Ideally suited for longer term cardiac rhythm monitoring
- High utility in various practice settings, including in and outpatient medicine, Home health care, sports medicine, EMS and cardiac and general rehabilitation.
- Highest standards of manufacturing and quality control
- Swiss Made product, manufactured and quality controlled based on zero error tolerance.
- One-year warranty against defects in material and manufacture.
- State-of-the-Art technical performance
- High-resolution display of recorded ECG tracings on the LCD display, including: Freeze function
- Storage (up to 99 individual ECG tracings for a total of 16 min.) and recall function, Audio/Alarm function.
- Automatic voltage amplification of recorded ECG tracings on the LCD display with normometric display of downloaded ECG records on the PC.
- Automatic pacemaker detection.
- Does not require any calibration or tuning. It contains no operator serviceable components
- SONOPLUS PC software for PC downloading of saved ECG tracings and PC-based printing and/or faxing/electronic mailing of downloaded ECG records.
